CB-Inspector: Eliminate all uncertainties in billet monitoring and handling
Modern steel plants need more than basic monitoring; they need smart systems that eliminate all uncertainty. At Selmatec, we believe in efficiency without compromise, and with this in mind we created the 2D-scanning CB-Inspector System, a complete solution that maximizes security for billet handling, not just on the cooling bed, but also during magnetic lifting.
The fundamental parts of the CB-Inspector System are the MP Line Scanner model, a tilt-unit and our very own software system, created specifically as an answer to the needs of steel applications. Using cutting-edge infrared technology, the line scanner ensures that the temperature of each billet is precisely measured.
On its own, the Line Scanner (MP300 model) operates at up to 300 lines per second, with a spectral sensitivity of 3.9µm, temperature range of 50–1,100°C, and a 90° swivel angle. This is expanded with the tilt unit’s 180° pivot, allowing the device to cover wide areas in 10-15 seconds, ensuring precise control to monitor cooling parameters for various steel grades. The spectral sensitivity of 3.9µm of the line scanner provides uniquely reliable temperature data and far exceeds the achievable accuracies of long-wave bolometric IR-cameras.
On the software side, the system collects the data from the Line Scanner, providing comprehensive analysis in real-time. This speed and efficiency allow you to detect anomalies and take proactive action to achieve a product of higher quality. Additionally, this prevents dangerous and expensive accidents caused by premature pick-ups if the billet temperature is not optimal.
When a single line scanner is not enough, make it 8! We aim to provide solutions as flexible as possible, and the 2D Scan is no different. With its modular design, it supports up to 8 scanning units, allowing plants of all sizes to benefit from customized coverage. Additionally, with options for data logging and report generation, manufacturers gain invaluable insights into cooling bed operations, making long-term optimization easier than ever.
Don’t leave your cooling bed monitoring to chance. Upgrade to Selmatec’s CB-Inspector System and experience the next level of precision and safety. Contact our experts today to learn how we can help optimize your plant’s performance.
