Hot Melt Applications: Multiple options for maximum versatility
Whether line, point or full-surface application, our inspection systems monitor it all! Discover your options and implement the best strategy for adhesive application:
When assembling a vehicle, it is important to ensure that every part is cleanly placed together. However, different pieces have challenging shapes or may require adhesive in extremely targeted spots, which demand your monitoring versatility.
Windows, carpets, dashboards and air filters are just some examples of areas that require extreme precision to ensure high quality and avoid glue leftovers. For example, in the case of window panes, the dispenser nozzle must apply adhesive in a thin line over the entire border for maximum sealing. Alternatively, adhesive application on a carpet must take into account the rugged texture to avoid future cracks.
Feel free to check our catalogue to find the ideal device according to your needs. Our experts are happy to help with inquiries:
- To monitor areas: ThermoView Camera
- To monitor lines: MP150/MP300 LineScanner / ThermoView Camera
- To monitor spots and fine details: Thermalert 4.0 and MI3 Pyrometers
ThermoView Camera:
- Wide temperature range: -10 to 1200 °C
- 320 x 240 (76,800 pixels) and 640 x 480 (307,200 pixels) resolution
- 9 or 60 Hz models available
- Field of View: horizontal 34º x 25.5º
- Spectral range: 8 - 14 μm
- Ambient temperatures to 200 °C with high temperature enclosure
- ThermoView software for industrial automation applications
- LAN/Ethernet with PoE for communication with the infrared camera provides access to integrated Web server and ThermoView Software
- GigE Vision interface
MP Line Scanner:
- High scanning speed of 300 lines per second
- up to 1024 measuring points per line
- wide range of spectral and temperature ranges
- high quality scanner motor with MTBF 40.000 h
- integrated Ethernet TCP/IP interface
- PC independent alarm output
- PC independent 4-20 mA interfaces (3 outputs)
- I/O module support for up to 10 sectors/zones (PC independent)
- internal line laser as sighting aid
- robust IP65 housing
- air purge attachment to maintain a clean measuring window
- ingerated water cooling
Thermalert 4.0:
- Conforms to Industry 4.0 standards
- Integrated laser sighting
- Galvanic isolated outputs
- Plastic lens option for food application
- Analog input for ambient compensation and adjusting emissivity setting
- USB for easy setup
- Simple, two-wire or digital installation
- Backward compatibility to old Raytek® and Ircon® in class sensors and accessories
- Fieldbus interface options: Ethernet, EtherNet / IP and PROFINET IO
- 1M & 2M Devices CQI-9 Rev. 4 conform
MI3 Pyrometer:
- IR temperature sensor range: -20 to 500°C (-4 to 932°F)
- Advanced feature set for OEM applications
- Accessories for air purging and lens protection
- 150 mSec (95%) response time
- Rugged IP 65 (NEMA-4) stainless steel housing
- DataTemp Multidrop software compatible
- Sensor status/self diagnostic LED indicator
- Adjustable signal processing
- MI3100 Series CQI-9 4th conform
