LIR Camera and Application Module: Preventing accidents in high-risk environments
Selmatec, leading provider of industrial automation solutions, is proud to introduce the LIR Camera and Application Module (APM) for thermal monitoring of critical systems.
The combination of the LIR Camera and APM provides reliable monitoring of various equipment and processes, including transformers, vacuum pumps, hydraulic pumps, medium voltage systems, heat treatment processes, and storage locations of flammable or combustible materials. It also monitors parking and charging areas of electric vehicles.
With integrated software, the LIR Camera and APM offer a wide range of monitoring and alarm functions, providing real-time alerts for critical issues. An intuitive, multilingual web interface also facilitates configuration, making it easy to set up and manage the system.
Forget about needless intervention. The APM can be easily integrated with other industrial systems. Various industrial interfaces such as Digital I/O, OPC UA, or ProfiNet are available, making it simple to install.
Contact us and learn more about the LIR Camera and APM, and how they can help your business improve its operations!
LIR Camera, key information:
- Measuring range: 25 ... 250°C
- Spectral range: 8 μm - 14 μm
- IR resolution (HxV): 320 px x 240 px
- Measuring accuracy: ± 2°C or ± 2% of the measured value
- Frame rate: 45 Hertz
- Shutter: Electromagnetic
- Focus: 100 mm - ∞ (manual focus)
- Interface: Gigabit Ethernet
- Sensor type: Uncooled microbolometer
- Lens: Germanium, f: 7 mm / 19 mm
- Weight: 150 g
- Housing size: 105 mm x 60 mm x 40 mm
- Frame rate: 45 Hertz
- Compliance: GenICam, GigE Vision, CE, RoHS, FCC
- Storage temperature: -20 - 80 °C
- Operating temperature: 23 - 50 °C
- Scope of delivery: Complete system solution, incl. commissioning and training
