Manufacturing electronics: Get rid of surprises and excel in your industry
Get rid of unpleasant surprises. Excel in your industry with renewed confidence in the accuracy of your manufacturing processes.
Thanks to its versatility and non-invasive operation, thermography earned its place as a monitoring staple in manufacturing plants, including the production electronic items.
The process to assemble electronics is extremely complex, as it involves small parts and your utmost precision. However, with thermal vision, you can take advantage of in-depth insight to find anomalies that stem from assembly errors or malfunction before it is too late.
Monitor hot spots, temperature distribution, heat dissipation and more! For this application, our TV40 IR-Camera and our pyrometers (MI3 Series/Thermalert 4.0) can reliably support you every step of the way with real-time feedback and high-end performance.
In our portfolio, you can find further specialized solutions, encompassing both software and hardware. Our experts are here to help you choose the best option tailored for your needs.
MI3 Pyrometer
- IR temperature sensor range: -20 to 500°C (-4 to 932°F)
- Advanced feature set for OEM applications
- Accessories for air purging and lens protection
- 150 mSec (95%) response time
- Rugged IP 65 (NEMA-4) stainless steel housing
- DataTemp Multidrop software compatible
- Sensor status/self diagnostic LED indicator
- Adjustable signal processing
- MI3100 Series CQI-9 4th conform
Thermalert 4.0
- Conforms to Industry 4.0 standards
- Integrated laser sighting
- Galvanic isolated outputs
- Plastic lens option for food application
- Analog input for ambient compensation and adjusting emissivity setting
- USB for easy setup
- Simple, two-wire or digital installation
- Backward compatibility to old Raytek® and Ircon® in class sensors and accessories
- Fieldbus interface options: Ethernet, EtherNet / IP and PROFINET IO
- 1M & 2M Devices CQI-9 Rev. 4 conform
ThermoView TV40
- IR-Fusion® technology (thermal and visible sighting) for easy alignment and added detail on blended images
- Pre-calibrated lens with remote motorized focus and multiple available field interchangeable lens options
- Discreet I/O alarms to interface to PLC
- IP67 (NEMA 4) rated with rugged housing allows for installation into harsh environments with air purge and other accessories available
- Wide temperature range: -10 to 1200 °C
- 320 x 240 (76,800 pixels) and 640 x 480 (307,200 pixels) resolution
- 9 or 60 Hz models available
- Field of View: horizontal 34º x 25.5º
- Spectral range: 8 - 14 μm
- Ambient temperatures to 200 °C with high temperature enclosure
- ThermoView software for industrial automation applications
- LAN/Ethernet with PoE for communication with the infrared camera provides access to integrated Web server and ThermoView Software
- GigE Vision interface
