Optimize your steel strip production and improve your savings
Despite the simplicity of the desired figure, steel strips will be damaged during manufacture if their temperature isn’t closely monitored. However, the environment is often extremely polluted, which complicates the task for several sensors.
This is why we recommend our Endurance Series Pyrometer, a ratio device that will guarantee accurate thermal profiling, even when the target is 95% obscured due to steam, dust and other particles. Furthermore, our MP Line Scanner is also a great addition for less polluted areas of your production line thanks to its ability to monitor the entire width of the band in one efficient take.
Without the advantages of our sensors or system solutions, your product may have its metallurgic properties altered during manufacture, which leads to low-quality strips that have to be scrapped.
Even more benefits! Besides high-quality products you also get:
- Increased productivity
- Less scrap
- Higher safety for your workers
- Reduced downtime
Contact our experts and find the ideal solution for your needs!
Endurance Series:
- Single color, two color and fiber optic models
- Temperature range: 50 to 3200 °C (122 to 5792 °F)
- Superior optical resolution to 300:1
- Spot sizes down to 0.6mm (0.02 inch)
- Fast response times down to 2 ms
- Easy adjustment with manual variable focus integrated head optics
- Through-the-lens sighting, with optional laser, LED or video aiming function
- Compact, rugged housings with IP65 (NEMA-4) rating
- Ethernet, Profinet and EtherNet/IP options
- Programmable relay output for control
- Simultaneous analog and digital outputs
- CQI-9 4th conform
MP Line Scanner:
- High scanning speed of 300 lines per second
- up to 1024 measuring points per line
- wide range of spectral and temperature ranges
- high quality scanner motor with MTBF 40.000 h
- integrated Ethernet TCP/IP interface
- PC independent alarm output
- PC independent 4-20 mA interfaces (3 outputs)
- I/O module support for up to 10 sectors/zones (PC independent)
- internal line laser as sighting aid
- robust IP65 housing
- air purge attachment to maintain a clean measuring window
- ingerated water cooling
