Tire Manufacturing: Solutions to optimize your process
In the production of tires, the temperature of the tire compound plays a decisive role and significantly influences the result. Therefore, it is crucial to monitor the different phases closely in order to detect defects as early as possible, which saves time and also helps to reduce the number of possible rejects or even complaints.
When mixing and extruding the tire compound, our IR line scanners, IR cameras or individual pyrometers, including suitable process-specific software, can provide data for reliable process control and consistently stabilize quality.
Thanks to the versatility of IR sensor technology, monitoring protocols can be used at various stages.
MI3 Compact Series:
- IR temperature sensor range: -20 to 500°C (-4 to 932°F)
- Advanced feature set for OEM applications
- Accessories for air purging and lens protection
- 150 mSec (95%) response time
- Rugged IP 65 (NEMA-4) stainless steel housing
- DataTemp Multidrop software compatible
- Sensor status/self diagnostic LED indicator
- Adjustable signal processing
- MI3100 Series CQI-9 4th conform
MP Line Scanner:
- Real-time thermal line-scanner system for continuous or discrete process measurements
- Up to 1024 measurement points per line
- Fast scan rates up to 150 lines per second
- Optical resolution up to 200:1
- Built-in line laser for rapid alignment
- On-board Ethernet TCP/IP communication
- Wide choice of models and spectral responses
IR-Camera:
- IR-Fusion® technology (thermal and visible sighting) for easy alignment and added detail on blended images
- Pre-calibrated lens with remote motorized focus and multiple available field interchangeable lens options
- Discreet I/O alarms to interface to PLC
- IP67 (NEMA 4) rated with rugged housing allows for installation into harsh environments with air purge and other accessories available
